| 型号 | 弯管能力 | 弯曲半径 | 弯曲角度 | 电机功率 | 工作压力 |
| 38NC | Φ38×2.0 | 200 | 185° | 4kw | 12MPa |
| 50NC | Φ50×2.5 | 250 | 185° | 5.5kw | 12MPa |
| 63NC | Φ63×3.0 | 300 | 185° | 5.5kw | 12MPa |
| 75NC | Φ75×3.5 | 350 | 185° | 7.5kw | 12MPa |
| 100NC | Φ100×4.5 | 400 | 185° | 11kw | 12MPa |
| 120NC | Φ120×5.0 | 500 | 185° | 15kw | 12MPa |
| 159NC | Φ159×10 | 550 | 185° | 22kw | 14MPa |
| 168NC | Φ168×14 | 700 | 185° | 22kw | 14MPa |
| 219NC | Φ219×18 | 850 | 185° | 30kw | 14MPa |
